    ISO9001 120V Zinc Plating Rectifier 60Hz 20000A Gold Plating

    Ask Lasest Price
    Brand Name : FEVER
    Model Number : KHS-13KA/120V
    Certification : ISO9001
    Price : negotiate
    Payment Terms : T/T
    Supply Ability : 1pcs/year
    Delivery Time : 100 days
    • Product Details
    • Company Profile

    ISO9001 120V Zinc Plating Rectifier 60Hz 20000A Gold Plating

    KHS-13KA/120V Full Automatic Electroplating Equipment Rectifier


    Intrudution:


    Rectifier transformer input power 11KV±5%; 50Hz±2%; three-phase three-wire system

    Power and control power supply 415V; 50Hz±2%, power 1KVA, and the power of pure water cooler is 3KVA. Three-phase four-wire system

    The rectifier becomes a double-reverse star-shaped twelve-pulse rectifier wiring mode.

    ISO9001 120V Zinc Plating Rectifier 60Hz 20000A Gold Plating


    Application:


    1.Plating: Chrome,Zine,Nickel,Copper,Gold,Silver
    2.Metal smelting: Aluminum,Copper, Zine, Lead,Manganese,Magnesium,etc
    3.Ionic membrane: Electrolysis of salt,etc
    4.Silicon carbide smelting & Graphitization furnace
    5.Experimental power supply
    6.Copper foil, aluminum foil special power supply
    7.Electrochemical: Chlor-alkali, etc
    8.Electrolysis: Copper,Zine,Tin,Lead,Aluminum foil,Copper foil


    Features:


    1) Small, light and high efficiency
    2) High frequency pulse current output
    3) Flexible use, simple operation
    4) Complete protection function


    Specification:


    AC input(V)

    C 220V± 10% 3ø 50/60HZ

    AC 380V± 10% 3ø 50/60HZ

    DC output(V)0~12V optional, digital display, adjustable
    DC output(A)0~20000A optional, digital display, adjustable
    Output power240KW
    Power factor0.93
    Output efficiency 80%
    Constant-current precision (%)0.01%
    Constant-voltage accuracy (%)0.5%
    Protection functionShort circuit protection/ overheating protection/ phase lack protection/ input over/ lowvoltage protection
    Environment temperature-10°c ~ 45°c
    Control modeLocal control/Remote control/ Local & Remote control
    Working modeConstant current/voltage
    Cooling wayWater cooling
    Remark

    Acousto-optical alarm can be provide when u selected

    485/PLC communication interface can be provide when u selected


    About Us


    Zibo Fever International Trade Co., Ltd. was established in 2017. Our company is mainly engaged in the import and export business of machinery and equipment project products, and provides long-term equipment spare parts and auxiliary materials for the steel and ceramic factories.


    FAQ


    1. Do you have after sales support?
    Yes, we are happy to give advice and we also have skilled technicians available across the world. We need your machines running in order to keep your business running.
    2.
    How long the machine could be made?
    Normally speaking, all the machines could be made without 45 working days. But if you need machines in a hurry, we can make it for you less than a month.
    3. What can you do if the machine broken?
    Our machine's warranty period is 12months, if the broken parts can't repair, we can send the new parts replace the broken parts freell, but you need pay the express cost yourself. if after warranty period, we can through negotiation to solve the problems,a nd we supply the technical support for the whole life of the equipment.
    4. Can you be responsible for transport?
    Yes, please tell me the destination port. We can help you to do the shipping if you need. we have rich experience in transport. We can give you the cheaper freight and send the machien to your country port.
